Welcome To Lakeshore Industrial, Inc.

Manufacturers of Custom Cage

Custom Cage Man - USALakeshore Industrial, Inc. manufactures personnel lifting platforms, Manbaskets / Man Baskets under the trade name Custom Cage®. These work platforms are available in a wide variety of dimensions and capacities. They are designed to be suspended directly from a crane hook or attached to a forklift. Custom Cages® are certified to meet or exceed all existing state and federal codes. Each cage is load tested prior to shipping.

Custom Cages® are available in any size, shape or material to meet your needs. Lakeshore Industrial, Inc. builds the highest quality industrial platforms / manbaskets made. We are dedicated to building personnel manbaskets for cranes and fork trucks. Custom Cage® Think Safety!

Custom Cage, Two Rivers, Wisconsin

48” x 48” x 86” W.L.L. 1,000 lbs.
Shown with optional Test Weight, Peaked Solid Steel Roof, Forklift Attachments, and Rubber Corner Bumpers.

  • CUSTOM CAGE
  • M-44 Manbasket
  • 48″ x 48″ x 86″
  • W.L.L. 1,000 lbs.
  • Peaked Solid Steel Roof
  • Forklift Attachments

Customer Support Email: lakeshoreind@lsol.net



CL-409

SPECIFICATIONS:

  • Meets or exceeds A.S.M.E. B30.23-latest specifications.
  • Designed to meet or exceed OSHA 29 CFR Subpart CC Part 1926.1431 final rule, and WCB Standards.  AWS D1.1 Certified
  • Welding procedures, all welds are spatter free and smooth.
  • Three year warranty.
  • Dimensions: 48″ W. x 108″ L. x 86” H. with 5′ work area @ 44″ high beyond pick point.
  • Working load limit; 900 lbs. overall – 500 lbs. w.l.l. on deck beyond pick point.
  • Easy on/ off detachable Test Weight system (1,125 lbs.) evenly distributes 125% test load on platform frame.
  • Five part bridle assembly w/shackles 4 legs of 5/8” wire rope 2 legs @ 5’ and 2 legs @ 6’ and 5th leg ¾” wire rope @ 6’ attached to master ring dedicated for personnel hoisting only.
  • Forklift tubes for easy transporting from one location to the next (6”x3”x1/8”).
  • V.L.M.H.P. (variable load multi hook points) adjustable lifting eyes for precise balance.®
  • Finish – Electrostatic powder coat (Color: Safety Yellow).
M-512 MATERIAL CAGE

SPECIFICATIONS:

  • Meets or exceeds A.S.M.E. B30.20-latest specifications.
  • Dimensions: 5’x12’x30”
  • Working load limit 5,000 lbs.
  • Two year warranty.
  • Square tube design.
  • Sides enclosed with expanded metal.
  • 4 Attachment points for cable suspension.
  • Fork pockets (7”x3”x3/16”) for transporting with fork truck.
  • Finish – Electrostatic powder coat (Color: Safety yellow).
  • Heavy Construction steel material baskets available in any sizes.
C-12FE

SPECIFICATIONS:

  • Designed to meet or exceed all State and Federal OSHA Regulations.
  • AWS D1.1 Certified Welding procedures, all welds are spatter free and smooth.
  • Two year warranty. * Dimensions: 44” x 34” x 75” high outside.
  • Working load limit 2,500 lbs.
  • Holds 12 cylinders
  • E-track strapping to secure cylinders
  • Solid steel roof with a Single pick point.
  • Fork lift tubes 3″x6″x1/8”.
  • Outward swinging lockable gate on one side with drop pin latch.
  • Ramp below gate for easy loading of your cylinders.
  • Finish – Electrostatic powder coat finish – safety green.
ME-488 Custom Rescue Cage

SPECIFICATIONS:

  • Meets or exceeds A.S.M.E. B30.23-latest specifications.
  • Designed to meet or exceed OSHA 29 CFR Subpart CC Part 1926.1431final rule, and WCB & CSA Standards.
  • AWS D1.1 Certified Welding procedures, all welds are spatter free and smooth.
  • Three year warranty.
  • Dimensions: 48”x96”x44”
  • Working load limit; 1,000 lbs.
  • 30″ Access door – Outward swinging drop pin latch.
  • Attachment points for bridle assembly.
  • Finish – Electrostatic powder coat : Safety Yellow.
  • Operating manual furnished inside of cage in a water proof compartment.
