Frequently asked questions

As industry leader we pride ourselves on being knowledgeable about the complexities surrounding man basket regulations. Here are just a few FAQ we receive. For more information be sure to check out our blog page.
OSHA follows the guidelines of ASME B30.23 and OSHA 29 CFR Subpart CC 1926.1431 standards for man baskets. Lakeshore Industrial builds our baskets to comply with all applicable guidelines.
Man baskets do not need to be recertified unless they have been modified, however it is required to inspect your man basket prior to each use and periodically for baskets that have not been used recently.
Bridle assemblies must be capable of supporting 5x the maximum intended load with each leg and master link tagged with the rated load. Rigging must always use a bolt type shackle with a locking cotter pin.
Trial lifts are required every time the crane moves to a new location. The trial lift shall be held a few feet off the ground for a minimum of 5 minutes. During the lift and after completion a designated competent person shall inspect the platform and rigging for any defects. For more click the following link. What is a test weight?
The bridle assembly is the rigging used to lift your cage. The bridle is required to be rotation resistant and rated at a capacity of 5x the total amount you will be lifting. We use a non-tear wire rope assembly.
The 5th leg of a bridle assembly is an additional safety option. The 5th leg attaches above the crane hook as an extra safety line in case of failure of the other 4 legs. This bridle is required in Canada. Washington requires a special “loop style 5th leg.”
According to ASME B30.23 a man basket should be inspected prior to every use. Look for damage or cracks in the steel frame, tears or fissures in the bridle assembly and any bending or bowing.
Forklift man baskets must have a means of securing the basket to the forklift, have at least a 5′ protective back with no more than 1/2″ openings, be equipped with safety harness tie off points and have guardrails between 39″-45″ in height.
Telehandler man baskets must be secured to the fork tines by utilizing a heavy duty pin system. Telehandler baskets also must not extend more than 10″ past the wheel wells to each side of the machine unless utilizing outriggers.
Yes, Lakeshore Industrial ships man baskets and material lifting baskets all over the world including Canada. Since 1998 we have created a presence in more than 50 countries around the world.
